Rubber Lined P Clips - 100 Pack

Surface Mount 12mm Band Width 0.6mm Thick

PPC005-ASH#100

£38.00

Delivery/Collection

Collect from Silicone Hose UK

Orders can be collected once you receive your ready-to-collect email.

Address

Silicone Hose UK

HolmeBank Business Park, Station Road
Unit 5
Mirfield WF14 8NA
Vereinigtes Königreich

Get Directions

Opening hours

Monday	07:00 – 19:00
Tuesday	07:00 – 19:00
Wednesday	07:00 – 18:00
Thursday	07:00 – 18:00
Friday	07:00 – 17:00
Saturday	07:00 – 13:00
Sunday	Closed

Bank holidays may affect our opening hours and delivery times.

Returns

It's OK to change your mind
Return within 30 days for a full refund*. Learn More

Shop safely

Secure your shopping experience with various safe and trusted payment methods.

Shop safely with us

Rubber Lined P Clip is a secure and durable fastening solution designed for mounting hoses, pipes, and cables in automotive, industrial, and construction applications. Constructed from zinc-plated solid steel with a protective rubber lining, the clip provides excellent clamping strength while cushioning the hose or pipe to prevent wear, vibration damage, and abrasion. Its P-shaped design allows for simple and reliable installation, keeping hoses neatly routed and fixed in place. With a wide operating temperature range of -50°C to +150°C (peaks up to +160°C), Rubber Lined P Clip is suitable for use in both indoor and outdoor environments where long-lasting, vibration-resistant support is required.

Key Features:

Material: Zinc-plated solid steel for strength and corrosion resistance.
Lining: Rubber lining to cushion hoses, reduce vibration, and prevent abrasion.
Design: P-shaped mounting clip for secure and tidy hose or pipe management.
Band Width: 12 mm for strong clamping force.
Band Thickness: 0.6 mm for durability while remaining easy to install.
Clip Range: Available from 5 mm to 38 mm diameters.
Operating Temperature: -50°C to +150°C (peak +160°C).
Applications: Automotive, industrial machinery, hydraulics, pneumatics, and general hose or cable management.

The combination of zinc-plated steel and rubber lining provides a strong, vibration-damping clamp suitable for high-performance environments. The lining protects against chafing and surface damage while the steel band ensures a secure hold, even under vibration or movement. Easy to fit with standard fixings, Rubber Lined P Clips allow quick installation and provide neat, professional routing of hoses and cables.

Applications include securing coolant hoses in vehicles, mounting pneumatic and hydraulic lines, fastening fuel hoses, protecting cables in machinery, and general pipe management in construction or maintenance. Rubber Lined P Clip offers a reliable and versatile solution for vibration-resistant hose and pipe support across a wide range of industries.

Specifications

Type: Rubber Lined P-Clip
Colour: Black
Standard: W1 / W4

Size Guide

Clip Range Diametermm	Band Widthmm	Band Thicknessmm	Material
5	12	0.6	W1

Measurements are nominal and may vary slightly.

How to size a clip

1

Measure over the hose, not the pipe

A clip closes around the outside of the hose once the hose is already on its fitting. That outside diameter is the clip size — the bore the hose runs on is not.

2

Or work it out from the hose's own figures

If the hose is not to hand, take its internal diameter and add twice the wall thickness — both are listed in that hose's own Size Guide. A 19 mm bore silicone hose has a 4.5 mm wall, so it measures 28 mm across the outside.

3

Use vernier calipers, keep the largest reading

Set the outer jaws across the widest point of the assembled joint and rotate 60° between readings. Hose is soft and rarely perfectly round, so size to the biggest figure.

4

Match the size to your figure

These are listed at a nominal diameter rather than a span, so choose the size that matches the outside of the hose you are holding — round up if you land between two.

Size the clip to the hose OD, not the bore. A 19 mm hose does not take a 19 mm clip — with a 4.5 mm wall it measures about 28 mm across the outside. Every figure on this page is the outside diameter the clip closes on.

Construction

Material

Zinc-plated solid steel

Strength and corrosion resistance

Design

P-shaped mounting clip

Secure and tidy hose or pipe management · -50°C to +150°C (peak +160°C)

Hold the run. Rubber lined.

P-shaped mounting clips that grip the pipe without chafing it.

CLAMPING RANGE

5mm to 35mm

RATED

−50°C to +150°C

MATERIAL

Zinc-plated solid steel

BAND WIDTH

12mm

How it's built

What it's made of.

Made from zinc-plated solid steel.

1

Material

Zinc-plated solid steel

Strength and corrosion resistance

2

Design

P-shaped mounting clip

Secure and tidy hose or pipe management-50°C to +150°C (peak +160°C)

Product gallery

Frequently Asked Questions.

Answers to the questions we’re asked most about sizing, fitment and performance.

Still can't find your answer?

Contact Us

What is in the pack?

One hundred rubber lined P-clips in one size, for fixing hose, pipe or cable runs to a bracket, panel or chassis rail.

Who is the 100 pack for?

Workshops, restorers, fabricators and fleet work - anywhere the same clip size gets used constantly. Per clip it is much cheaper than singles, and it stops the job stalling because you are three clips short.

What sizes do you stock?

5mm, 6mm, 8mm, 10mm, 13mm, 16mm, 21mm, 25mm, 29mm and 35mm. Size to the outside diameter of the hose or pipe being clamped, not its bore. The box is a single size.

What are they made from?

Zinc-plated solid steel with a rubber lining. The band is 12mm wide and 0.6mm thick, rated -50C to +150C with peaks to +160C.

Why does the rubber lining matter?

It cushions the run against vibration and stops a steel band cutting into the hose. An unlined clip will wear a flat and then a hole into silicone or rubber.

How far apart should I fit them?

Typically every 300 to 500mm on a straight run, and always just before and after a bend, a bulkhead pass, or anywhere the hose passes near an edge or a moving part.
